IS 3200Z

Premium Power and Performance

You don't so much perform landscape work with the IS 3200Z as take a leisurely cruise while incidentally cutting the lawn. When our engineers set out to reimagine Ferris's already impressive IS 3100Z, they ratcheted up so many specs, the resulting lawn machine is rugged yet refined – a truly premium turf groomer.

FIND A DEALER
ferrismowers /

Product Details

500 Hour Oil Change (Select Models)

Vanguard™ Engines with Oil Guard System reduce maintenance time and costs by up to 60%.*

Acres Per Hour

Pillow block bearings on control mounts makes for long lasting smooth, precision controls.

Tramsission Oil Cooler

Transmission oil cooler cools oil for enhanced transmission longevity.

Cast-Iron Spindles

Greasable cast-iron spindles for strength and durability (61" model).

Hydro-Gear Drive System

Hydro-Gear® commercial engineered drive system is designed for high performance and is fully serviceable.

*Cost savings based on oil maintenance with 100 hour interval versus Oil Guard System 500 hour service interval.

HP (gross) * 37
Engine Brand Vanguard EFI with Oil Guard ™
Power Take Off (PTO) Electric
Number of Cylinders 2, V-Twin
Starting Electric
Fuel Tank Capacity (litre) 42
Cutting Width (cm) 155
Cutting Height (cm) 3.8 - 12.7
Deck Construction iCD™ Cutting System; 10-gauge, fabricated, double top deck, double reinforced side skirts, overlap welded corners
Spindles Hercules™ Spindles
Suspension Rear coil-over-shocks with dual cast-iron maintenance-free suspension arms and front independent adjustable shocks
Transmission Dual commercial Hydro-Gear® ZT-5400Powertrain® transaxles with 9" cooling fans
Drive Axles 3.4 Tapered
Drive Tyres (in) 24 x 12 x 12
Caster Tyres (in) 13 x 6.5
Ground Speed - Fwd (km/h) 19.3
Ground Speed - Rev (km/h) 9.5
Overall Length (cm) 215
Overall Width (cm) Deflector Down / Deflector Up 169
Dry Weight (kg) 687
Seat Package Premium adjustable high-back seat
Roll-over Protection System Standard
Instrumentation Hour meter, Fuel gauge
Controls/Safety Group Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit
Parking Break / Safety Circuit Internal transaxles
Warranty (Engine) ** 3-Year Limited Manufacturer's Warranty
Warranty (Balance of Machine) ** 2 Year Transmission Warranty, 2+2 Warranty - 2 Year Commercial Use, additional 2 years (or 500 hours for Non-Commercial Use), frontto- rear, parts & labour excluding belts, blades, tyres and brake pads

*All power levels are stated gross horsepower per SAE J1940 as rated by Briggs & Stratton.
All power levels are stated gross horsepower per SAE J2723 as rated by Kawasaki.
**See operator's manual or dealer for complete warranty details. Length of engine warranty coverage varies by manufacturer.

HP (gross) * 37
Engine Brand Vanguard EFI with Oil Guard ™
Power Take Off (PTO) Electric
Number of Cylinders 2, V-Twin
Starting Electric
Fuel Tank Capacity (litre) 42
Cutting Width (cm) 183
Cutting Height (cm) 3.8 - 12.7
Deck Construction iCD™ Cutting System; 10-gauge, fabricated, double top deck, double reinforced side skirts, overlap welded corners
Spindles Hercules™ Spindles
Suspension Rear coil-over-shocks with dual cast-iron maintenance-free suspension arms and front independent adjustable shocks
Transmission Dual commercial Hydro-Gear® ZT-5400Powertrain® transaxles with 9" cooling fans
Drive Axles 3.4Tapered
Drive Tyres (in) 24 x 12 x 12
Caster Tyres (in) 13 x 6.5
Ground Speed - Fwd (km/h) 19.3
Ground Speed - Rev (km/h) 9.5
Overall Length (cm) 215
Overall Width (cm) Deflector Down / Deflector Up 194
Dry Weight (kg) 687
Seat Package Premium adjustable high-back seat
Roll-over Protection System Standard
Instrumentation Hour meter, Fuel gauge
Controls/Safety Group Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit
Parking Break / Safety Circuit Internal transaxles
Warranty (Engine) ** 3-Year Limited Manufacturer's Warranty
Warranty (Balance of Machine) ** 2 Year Transmission Warranty, 2+2 Warranty - 2 Year Commercial Use, additional 2 years (or 500 hours for Non-Commercial Use), frontto- rear, parts & labour excluding belts, blades, tyres and brake pads

*All power levels are stated gross horsepower per SAE J1940 as rated by Briggs & Stratton.
All power levels are stated gross horsepower per SAE J2723 as rated by Kawasaki.
**See operator's manual or dealer for complete warranty details. Length of engine warranty coverage varies by manufacturer.
