500S Zero Turn Mower

ESSENTIAL PRODUCTIVITY

The 500S zero turn mower is packed with essential features to deliver reliable productivity and performance. The differentiating 4 point suspension saves your body from the pains of continuous mowing. Plus, commercial-like performance and extras like the LED headlight make for a confident mowing experience season after season.

48+"

Cutting Width

24+ HP

Power Rating*

8.5 MPH

Ground Speed

3-Years

Limited Warranty†

Features

Patented Suspension

The 500S comes equipped with swingarm rear and pivoting front coil-over shocks meaning less concern for uneven ground, and more focus on getting work done.

Commercial Grade Power

Briggs & Stratton® Commercial Series engines are built with the ultimate in dust and particle filtration, an advanced debris management system and a beefed-up cylinder block structure.

Convenient Components

Confidently mow day or dusk with the standard integrated LED headlight, premium mid-back seat, and improved engine protection.

Fabricated Mowing Deck

The fabricated 10-gauge steel mowing deck is durable and provides reliable cutting performance in a variety of conditions.

Hydro-Gear Transaxles

Dual-commercial transaxles with 7" cooling fans repel debris and provide consistent power.

Confident Traction

22-inch rear-drive tires and large front casters ensure wheel contact for dependable traction in varying conditions.

Specifications

Only 2 products can be compared at once. Please remove one of your selections to compare this product.

Only 3 products can be compared at once. Please remove one of your selections to compare this product.

At least one product must be displayed. Please select another option to remove this product

US MSRP ^
$5,799.00
CAN MSRP ^
$6,849.00
Engine Brand
Briggs & Stratton® Commercial Series
Engine Power Rating *
25
Displacement (cc)
724
PTO
Electric
Cylinders
2
Starter
Electric
Fuel Type
Gasoline
Fuel Tank Capacity (gal)
3
Hour Meter/Instrumentation
Dual-function hour meter, fuel level gauge in tank
Cutting Width (in)
48
Cutting Height (in)
1.5 - 4.5
Spindles
Aluminum Greaseable
Suspension
Front and rear adjustable dual coil-over shocks
Transmission
Dual Hydro-Gear® ZT-2800® transaxles with 7" cooling fans
Deck Construction
Fabricated 10-gauge
Drive Axles (in)
1
Caster Tires (in)
13 X 6.5-6
Drive Tires (in)
22 x 10 - 10
Ground Speed-Fwd (mph)
0-8.5
Ground Speed-Rev (mph)
0-4
Overall Length (in)
78.5
Overall Width (in) Deflector Down/Deflector Up
53
Dry Weight (lbs)
765
Seat Package
Mid-back seat with arm rests
Certified Roll-over Protection System
N/A
Controls / Safety Group
Seat activated engine kill, clutch Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls switch
Parking Brake / Safety Circuit
Hand operated Internal transaxle brake
Warranty (Engine) †
3-Year Manufacturer’s Limited Warranty (36 month)
Warranty (Balance of Machine) †
Consumer Warranty (Product), 3-Years / Commercial Warranty (Product), 90-Days / Fabricated Mower Deck Warranty, Lifetime

* Power rated by engine manufacturer.
† See operator's manual or dealer for complete warranty details. Refer to engine operator's manual for engine warranty.
^ Suggested prices will vary by market. Set-up, delivery, documentation and destination fees not included. See dealer for details. Features vary by model. We reserve the right to change specifications, features and pricing without notice.

US MSRP ^
$6,199.00
CAN MSRP ^
$7,899.00
Engine Brand
Briggs & Stratton® Commercial Series
Engine Power Rating *
25
Displacement (cc)
724
PTO
Electric
Cylinders
2
Starter
Electric
Fuel Type
Gasoline
Fuel Tank Capacity (gal)
3
Hour Meter/Instrumentation
Dual-function hour meter, fuel level gauge in tank
Cutting Width (in)
52
Cutting Height (in)
1.5 - 4.5
Spindles
Aluminum Greaseable
Suspension
Front and rear adjustable dual coil-over shocks
Transmission
Dual Hydro-Gear® ZT-3100® transaxles with 7" cooling fans
Deck Construction
Fabricated 10-gauge
Drive Axles (in)
1
Caster Tires (in)
13 X 6.5-6
Drive Tires (in)
22 X 11 - 10
Ground Speed-Fwd (mph)
0-8.5
Ground Speed-Rev (mph)
0-4
Overall Length (in)
78.5
Overall Width (in) Deflector Down/Deflector Up
64
Dry Weight (lbs)
855
Seat Package
Mid-back seat with arm rests
Certified Roll-over Protection System
N/A
Controls / Safety Group
Seat activated engine kill, clutch Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls switch
Parking Brake / Safety Circuit
Hand operated Internal transaxle brake
Warranty (Engine) †
3-Year Manufacturer’s Limited Warranty (36 month)
Warranty (Balance of Machine) †
Consumer Warranty (Product), 3-Years / Commercial Warranty (Product), 90-Days / Fabricated Mower Deck Warranty, Lifetime

* Power rated by engine manufacturer.
† See operator's manual or dealer for complete warranty details. Refer to engine operator's manual for engine warranty.
^ Suggested prices will vary by market. Set-up, delivery, documentation and destination fees not included. See dealer for details. Features vary by model. We reserve the right to change specifications, features and pricing without notice.

US MSRP ^
$6,749.00
CAN MSRP ^
$8,399.00
Engine Brand
Briggs & Stratton® Commercial Series
Engine Power Rating *
25
Displacement (cc)
724
PTO
Electric
Cylinders
2
Starter
Electric
Fuel Type
Gasoline
Fuel Tank Capacity (gal)
3
Hour Meter/Instrumentation
Dual-function hour meter, fuel level gauge in tank
Cutting Width (in)
61
Cutting Height (in)
1.5 - 4.5
Spindles
Aluminum Greaseable
Suspension
Front and rear adjustable dual coil-over shocks
Transmission
Dual Hydro-Gear® ZT-3100® transaxles with 7" cooling fans
Deck Construction
Fabricated 10-gauge
Drive Axles (in)
1
Caster Tires (in)
13 X 6.5-6
Drive Tires (in)
22 X 11 - 10
Ground Speed-Fwd (mph)
0-8.5
Ground Speed-Rev (mph)
0-4
Overall Length (in)
80
Overall Width (in) Deflector Down/Deflector Up
74
Dry Weight (lbs)
860
Seat Package
Mid-back seat with arm rests
Certified Roll-over Protection System
N/A
Controls / Safety Group
Seat activated engine kill, clutch Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls switch
Parking Brake / Safety Circuit
Hand operated Internal transaxle brake
Warranty (Engine) †
3-Year Manufacturer’s Limited Warranty (36 month)
Warranty (Balance of Machine) †
Consumer Warranty (Product), 3-Years / Commercial Warranty (Product), 90-Days / Fabricated Mower Deck Warranty, Lifetime

* Power rated by engine manufacturer.
† See operator's manual or dealer for complete warranty details. Refer to engine operator's manual for engine warranty.
^ Suggested prices will vary by market. Set-up, delivery, documentation and destination fees not included. See dealer for details. Features vary by model. We reserve the right to change specifications, features and pricing without notice.

US MSRP ^
$6,749.00
CAN MSRP ^
$8,749.00
Engine Brand
Kawasaki® FR730V
Engine Power Rating *
24
Displacement (cc)
726
PTO
Electric
Cylinders
2
Starter
Electric
Fuel Type
Gasoline
Fuel Tank Capacity (gal)
3
Hour Meter/Instrumentation
Dual-function hour meter, fuel level gauge in tank
Cutting Width (in)
61
Cutting Height (in)
1.5 - 4.5
Spindles
Aluminum Greaseable
Suspension
Front and rear adjustable dual coil-over shocks
Transmission
Dual Hydro-Gear® ZT-3100® transaxles with 7" cooling fans
Deck Construction
Fabricated 10-gauge
Drive Axles (in)
1
Caster Tires (in)
13 X 6.5-6
Drive Tires (in)
22 X 11 - 10
Ground Speed-Fwd (mph)
0-8.5
Ground Speed-Rev (mph)
0-4
Overall Length (in)
80
Overall Width (in) Deflector Down/Deflector Up
74
Dry Weight (lbs)
860
Seat Package
Mid-back seat with arm rests
Certified Roll-over Protection System
N/A
Controls / Safety Group
Seat activated engine kill, clutch Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls switch
Parking Brake / Safety Circuit
Hand operated Internal transaxle brake
Warranty (Engine) †
3-Year Manufacturer’s Limited Warranty (36 month)
Warranty (Balance of Machine) †
Consumer Warranty (Product), 3-Years / Commercial Warranty (Product), 90-Days / Fabricated Mower Deck Warranty, Lifetime

* Power rated by engine manufacturer.
† See operator's manual or dealer for complete warranty details. Refer to engine operator's manual for engine warranty.
^ Suggested prices will vary by market. Set-up, delivery, documentation and destination fees not included. See dealer for details. Features vary by model. We reserve the right to change specifications, features and pricing without notice.

US MSRP ^
$5,799.00
$6,199.00
$6,749.00
$6,749.00
CAN MSRP ^
$6,849.00
$7,899.00
$8,399.00
$8,749.00
Engine Brand
Briggs & Stratton® Commercial Series
Briggs & Stratton® Commercial Series
Briggs & Stratton® Commercial Series
Kawasaki® FR730V
Engine Power Rating *
25
25
25
24
Displacement (cc)
724
724
724
726
PTO
Electric
Electric
Electric
Electric
Cylinders
2
2
2
2
Starter
Electric
Electric
Electric
Electric
Fuel Type
Gasoline
Gasoline
Gasoline
Gasoline
Fuel Tank Capacity (gal)
3
3
3
3
Hour Meter/Instrumentation
Dual-function hour meter, fuel level gauge in tank
Dual-function hour meter, fuel level gauge in tank
Dual-function hour meter, fuel level gauge in tank
Dual-function hour meter, fuel level gauge in tank
Cutting Width (in)
48
52
61
61
Cutting Height (in)
1.5 - 4.5
1.5 - 4.5
1.5 - 4.5
1.5 - 4.5
Spindles
Aluminum Greaseable
Aluminum Greaseable
Aluminum Greaseable
Aluminum Greaseable
Suspension
Front and rear adjustable dual coil-over shocks
Front and rear adjustable dual coil-over shocks
Front and rear adjustable dual coil-over shocks
Front and rear adjustable dual coil-over shocks
Transmission
Dual Hydro-Gear® ZT-2800® transaxles with 7" cooling fans
Dual Hydro-Gear® ZT-3100® transaxles with 7" cooling fans
Dual Hydro-Gear® ZT-3100® transaxles with 7" cooling fans
Dual Hydro-Gear® ZT-3100® transaxles with 7" cooling fans
Deck Construction
Fabricated 10-gauge
Fabricated 10-gauge
Fabricated 10-gauge
Fabricated 10-gauge
Drive Axles (in)
1
1
1
1
Caster Tires (in)
13 X 6.5-6
13 X 6.5-6
13 X 6.5-6
13 X 6.5-6
Drive Tires (in)
22 x 10 - 10
22 X 11 - 10
22 X 11 - 10
22 X 11 - 10
Ground Speed-Fwd (mph)
0-8.5
0-8.5
0-8.5
0-8.5
Ground Speed-Rev (mph)
0-4
0-4
0-4
0-4
Overall Length (in)
78.5
78.5
80
80
Overall Width (in) Deflector Down/Deflector Up
53
64
74
74
Dry Weight (lbs)
765
855
860
860
Seat Package
Mid-back seat with arm rests
Mid-back seat with arm rests
Mid-back seat with arm rests
Mid-back seat with arm rests
Certified Roll-over Protection System
N/A
N/A
N/A
N/A
Controls / Safety Group
Seat activated engine kill, clutch Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls switch
Seat activated engine kill, clutch Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls switch
Seat activated engine kill, clutch Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls switch
Seat activated engine kill, clutch Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls switch
Parking Brake / Safety Circuit
Hand operated Internal transaxle brake
Hand operated Internal transaxle brake
Hand operated Internal transaxle brake
Hand operated Internal transaxle brake
Warranty (Engine) †
3-Year Manufacturer’s Limited Warranty (36 month)
3-Year Manufacturer’s Limited Warranty (36 month)
3-Year Manufacturer’s Limited Warranty (36 month)
3-Year Manufacturer’s Limited Warranty (36 month)
Warranty (Balance of Machine) †
Consumer Warranty (Product), 3-Years / Commercial Warranty (Product), 90-Days / Fabricated Mower Deck Warranty, Lifetime
Consumer Warranty (Product), 3-Years / Commercial Warranty (Product), 90-Days / Fabricated Mower Deck Warranty, Lifetime
Consumer Warranty (Product), 3-Years / Commercial Warranty (Product), 90-Days / Fabricated Mower Deck Warranty, Lifetime
Consumer Warranty (Product), 3-Years / Commercial Warranty (Product), 90-Days / Fabricated Mower Deck Warranty, Lifetime

* Power rated by engine manufacturer.
† See operator's manual or dealer for complete warranty details. Refer to engine operator's manual for engine warranty.
^ Suggested prices will vary by market. Set-up, delivery, documentation and destination fees not included. See dealer for details. Features vary by model. We reserve the right to change specifications, features and pricing without notice.
