• Patented Suspension Technology for comfort and longevity
  • Cyclonic Filter in-built into the proven Commercial Series V-Twin
  • Cup holder, storage compartment and visible fuel gauge
  • Replaceable oil filters and overflow reservoirs fitted to the Premium transmissions

ferrismowers /

Product Details

Gross Horsepower* (HP) 23
Engine Series Commercial Series
Power Take Off (PTO) Electric
Number of Cylinders 2
Starting Electric
Fuel Tank Capacity (L) 21
Width of Cut cm (in) 122 (48)
Height of Cut cm (in) 3.8-11.4 (1.5-4.5)
Deck Construction Fabricated, 10-gauge
Spindle Type Cast-Aluminium Greasable
Suspension Style Patented Suspension system, Front and rear adjustable dual coil-over shocks
Transmission Brand Dual commercial Hydro-Gear® ZT-3100® Transaxles with 7” cooling fans
Drive Axles cm (in) 1.0 Tapered
Drive Tires (in) 20 x 10 - 10
Caster Tires (in) 11 x 4.5
Ground Speed FWD (km/h) 0-12.8
Ground Speed REV (km/h) 0-6.4
Overall Length cm (in) 203 (80)
Overall Width cm (in) 159 (63)
Seat Package Mid-back seat
Rollover Protection System (ROPS) n/a
Instrumentation Fuel level gauge in tank, Hour meter
Safety Group / Controls Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls
Parking Brake Internal Brake in Transaxle
Optional Extras Collection systems, mulch kit, trailer hitch kit, LED light kit, service jack
Limited Warranty (Engine)† 2 Years
Limited Warranty (Product)† 2 Years
Limited Warranty (Balance of Machine)† 2 Year Commercial Use, additional 2 years (or 500 hours for Non-Commercial Use), front-to-rear, parts & labour excluding belts, blades, tyres and brake pads

* Power levels rated by engine manufacturer.
† Terms and conditions apply. See owners manual or ferrisindustries.com for details.
