42 - 52
Cutting Width (in)
25
Power Rating* (HP)
0 - 12.8
Ground Speed (kph)
3-Years
Limited Warranty†
Features
Specifications
Only 2 products can be compared at once. Please remove one of your selections to compare this product.
Only 3 products can be compared at once. Please remove one of your selections to compare this product.
At least one product must be displayed. Please select another option to remove this product
Part Number
2691384
Engine Brand
Briggs & Stratton® Commercial Series
Engine Power Rating (HP) *
25
Displacement (cc)
724
PTO
Electric
Cylinders
2
Starter
Electric
Fuel Tank Capacity (litres)
11.4
Cutting Width in(cm)
42 (106)
Cutting Height in(cm)
1.5 - 4.5 (38 - 114)
Spindles
Aluminium greaseable
Deck Construction
12-gauge, fabricated
Deck Discharge Type
Side Discharge
Suspension
Front coil-over shocks
Transmission
Dual Hydro-Gear® ZT-2800® Premium transmissions with charge pumps
Drive Axles (in)
1.00
Caster Tyres (in)
11 x 4 - 5
Drive Tyres (in)
20 x 7 - 10
Ground Speed-Fwd (kph)
0 - 12.8
Ground Speed-Rev (kph)
0 - 6.43
Overall Length (mm)
1867
Overall Width (mm) Deflector Down / Up
1400 / 1120
Dry Weight (kg)
342
Seat Package
Contour with armrests
Instrumentation
Fuel level gauge, hour meter
ROPS (Rollover Protection System)
N/A
Controls / Safety Group
Adjustable twin fold out 1" tubular steering levers with comfort grip
Parking Brake / Safety Circuit
Integrated transaxle brake
Warranty (Engine) †
2-Year commercial limited manufacturer's warranty
Warranty (Balance of Machine) †
3-Year Limited OR 565 hours, whichever comes first.
* Power levels rated by engine manufacturer.
† See operator's manual or dealer for complete warranty details. Refer to engine operator's manual for engine warranty.
Part Number
2691386
Engine Brand
Briggs & Stratton® Commercial Series
Engine Power Rating (HP) *
25
Displacement (cc)
724
PTO
Electric
Cylinders
2
Starter
Electric
Fuel Tank Capacity (litres)
11.4
Cutting Width in(cm)
52 (132)
Cutting Height in(cm)
1.5 - 4.5 (38 - 114)
Spindles
Aluminium greaseable
Deck Construction
10-gauge, fabricated
Deck Discharge Type
Side Discharge
Suspension
Front and rear adjustable coil-over shocks
Transmission
Dual Hydro-Gear® ZT-2800® premium transmissions with charge pumps
Drive Axles (in)
1.00
Caster Tyres (in)
11 x 4 - 5
Drive Tyres (in)
20 x 10 - 10
Ground Speed-Fwd (kph)
0 - 12.8
Ground Speed-Rev (kph)
0 - 6.43
Overall Length (mm)
1867
Overall Width (mm) Deflector Down / Up
1650 / 1380
Dry Weight (kg)
342
Seat Package
Contour with armrests
Instrumentation
Fuel level gauge, hour meter
ROPS (Rollover Protection System)
N/A
Controls / Safety Group
Adjustable twin fold out 1" tubular steering levers with comfort grip
Parking Brake / Safety Circuit
Integrated transaxle brake
Warranty (Engine) †
2-Year commercial limited manufacturer's warranty
Warranty (Balance of Machine) †
3-Year Limited OR 565 hours, whichever comes first.
* Power levels rated by engine manufacturer.
† See operator's manual or dealer for complete warranty details. Refer to engine operator's manual for engine warranty.
