IS 700Z

Outstanding Value Productivity

The IS® 700Z Series is an amazing value! Featuring our exclusive suspension technology, iCD™ Cutting System, heavy-duty Hydro-Gear® drive system and up to 16 km/h speeds, this mower is full of features to increase the operator’s productivity. You’ll mow more lawn in less time.

Features

Specifications

Engine Power Rating (HP) *

PTO

Electric

Cylinders

Starter

Electric

Fuel Tank Capacity (litres)

Cutting Width in(cm)

155, 132 (61, 52)

Cutting Height in(cm)

3.8-12.7 (1.5 - 5)

Spindles

Aluminum

Deck Construction

iCD™ Cutting System; 10-gauge, fabricated, double top deck, double reinforced side skirts, overlap welded corners

Suspension

Adjustable rear coil-over-shocks and pivoting front axle with shocks

Drive Axles (in)

3.2 (1.25) Tapered

Caster Tyres (in)

13 x 5

Drive Tyres (in)

22 x 11 - 10 (48)

Ground Speed-Fwd (kph)

0 - 16

Ground Speed-Rev (kph)

0 - 9.6

Overall Length (mm)

206

Overall Width (mm) Deflector Down / Up

171

Dry Weight (kg)

408

Seat Package

Mid-back seat

Instrumentation

Hour meter, Fuel gauge

ROPS (Rollover Protection System)

Standard

Parking Brake / Safety Circuit

Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit / adjustable twin steering controls

Warranty (Balance of Machine) †

4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 4 years (48 months) unlimited hours. Belts, tires, brake pads, battery, blades: 90 days

Parking Brake

Internal transaxles

Engine Series

Commercial Series

Warranty Commercial Power Source Info

2 Year Limited Manufacturer's Warranty

_{*All power levels are stated gross horsepower per SAE J1940 as rated by Briggs & Stratton.
†See operator's manual or dealer for complete warranty details. Length of engine warranty coverage varies by manufacturer.}
