    ISX 800 Zero Turn Mowers
    ISX 800 Zero Turn Mowers

    ISX™ 800 Zero Turn Mowers

    LANDSCAPER'S LEVERAGE

    Featuring the next generation of Ferris suspension technology – ForeFront™ Suspension, a 2-belt iCD™ cutting system, heavy-duty Hydro-Gear® drive system and travel speeds up to 16 kph, the ISX™ 800 is engineered to increase efficiency and operator comfort.

    52 - 61

    Cutting Width (in)

    27

    Power Rating* (HP)

    0 - 16.1

    Ground Speed (kph)

    4-Years

    Limited Warranty†
    Feature

    Features

    Forefront™ Suspension System

    The system utilises four upper and lower control rods and mower-specific shocks that ensure the front caster bearing remains vertical through the full range of travel. This controlled motion results in a smoother ride, more precise tracing of the terrain and an improved cut.

    Ride-On Mower Warranties†

    Coil-Over-Shocks and all suspension-related components are covered for 5 years (60 months), for unlimited hours. We are committed to providing performance, productivity and durability.

    Integrated Transmission

    Commercial Hydro-Gear® ZT-3400™ transaxles, with 7" cooling fans, are designed for high performance and are fully serviceable.

    EFI-ETC Engine Technology

    Models feature the Briggs & Stratton Commercial Series engine with EFI-ETC technology for easy starting and smooth performance.

    Easy Access

    Quick removal of the floor pan provides convenient access to the top of the deck for easy cleaning and service.

    iCD™ Cutting System

    iCD™ Cutting System was engineered to produce the best possible cut in a multitude of conditions. The ISX™ 800 is equipped with a 2-belt deck and provides a 3-year belt limited warranty (See operator’s manual for complete warranty details).

    Mower Spindles

    Cast-aluminum greaseable spindles feature 1” shaft with 2.5” x 1” dual ball bearings with top access grease fittings and pressure relief valve.

    Kilometres per Hour

    Up to 16.1 km/h ground speed, reverse 8.1 km/h.

    Specifications

    Only 2 products can be compared at once. Please remove one of your selections to compare this product.

    Only 3 products can be compared at once. Please remove one of your selections to compare this product.

    At least one product must be displayed. Please select another option to remove this product

    Part Number
    5902085
    Engine Brand
    Briggs & Stratton® CXi Series EFI-ETC
    Engine Power Rating (HP) *
    27
    Displacement (cc)
    810
    PTO
    Electric
    Cylinders
    2
    Starter
    Electric
    Fuel Tank Capacity (litres)
    20.8
    Cutting Width in(cm)
    52 (132)
    Cutting Height in(cm)
    1.5 - 5 (38 - 127)
    Spindles
    Aluminium Greaseable
    Deck Construction
    iCD™ Cutting System, 2-belt
    Suspension
    ForeFront™ Suspension System - Front independent with four cast-iron control rods paired with medium size adjustable coil-over shocks and a rear swing-arm with large adjustable coil-over shocks
    Transmission
    Dual commercial Hydro-Gear® ZT-3400® transaxles with 7" cooling fans
    Drive Axles (in)
    1.125
    Caster Tyres (in)
    13 x 6.5 - 6
    Drive Tyres (in)
    23 x 10.5 - 12
    Ground Speed-Fwd (kph)
    0 - 16.1
    Ground Speed-Rev (kph)
    0 - 8.1
    Overall Length (mm)
    2058
    Overall Width (mm) Deflector Down / Up
    1651 / 1448
    Dry Weight (kg)
    508
    Seat Package
    Premium mid back adjustable suspension seat with armrests
    Instrumentation
    Dual-function hour meter, fuel level gauge in tank
    ROPS (Rollover Protection System)
    180° foldable
    Controls / Safety Group
    Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit/adjustable twin steering controls
    Parking Brake / Safety Circuit
    Hand operated internal transaxle brake
    Warranty (Engine) †
    3-Year limited manufacturer's warranty
    Warranty (Balance of Machine) †
    4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 5 years (60 months) unlimited hours. Coverage on other components varies, please see operator’s manual for complete details.

    We reserve the right to change specifications, features and pricing without notice. Products may vary from images shown.
    * Power levels rated by engine manufacturer.
    † See operator's manual or dealer for complete warranty details. Refer to engine operator's manual for engine warranty.

    Part Number
    5902038
    Engine Brand
    Briggs & Stratton® CXi Series EFI-ETC
    Engine Power Rating (HP) *
    27
    Displacement (cc)
    810
    PTO
    Electric
    Cylinders
    2
    Starter
    Electric
    Fuel Tank Capacity (litres)
    20.8
    Cutting Width in(cm)
    61 (155)
    Cutting Height in(cm)
    1.5 - 5 (38 - 127)
    Spindles
    Aluminium Greaseable
    Deck Construction
    iCD™ Cutting System, 2-belt
    Suspension
    ForeFront™ Suspension System - Front independent with four cast-iron control rods paired with medium size adjustable coil-over shocks and a rear swing-arm with large adjustable coil-over shocks
    Transmission
    Dual commercial Hydro-Gear® ZT-3400® transaxles with 7" cooling fans
    Drive Axles (in)
    1.125
    Caster Tyres (in)
    13 x 6.5 - 6
    Drive Tyres (in)
    23 x 10.5 - 12
    Ground Speed-Fwd (kph)
    0 - 16.1
    Ground Speed-Rev (kph)
    0 - 8.1
    Overall Length (mm)
    2108
    Overall Width (mm) Deflector Down / Up
    1905 / 1613
    Dry Weight (kg)
    543
    Seat Package
    Premium mid back adjustable suspension seat with armrests
    Instrumentation
    Dual-function hour meter, fuel level gauge in tank
    ROPS (Rollover Protection System)
    180° foldable
    Controls / Safety Group
    Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit/adjustable twin steering controls
    Parking Brake / Safety Circuit
    Hand operated internal transaxle brake
    Warranty (Engine) †
    3-Year limited manufacturer's warranty
    Warranty (Balance of Machine) †
    4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 5 years (60 months) unlimited hours. Coverage on other components varies, please see operator’s manual for complete details.

    We reserve the right to change specifications, features and pricing without notice. Products may vary from images shown.
    * Power levels rated by engine manufacturer.
    † See operator's manual or dealer for complete warranty details. Refer to engine operator's manual for engine warranty.
